Maximum Off-grid Apparent Power 2.0 kVA / 2.3 kVA / 4.0 kVA (for 1 min)
eps_phase
—
eps_rated_power_va
Nominal Off-grid Output Power 1.7 kVA / 2.0 kVA / 3.6 kVA (at the 110 V / 127 V / 220 V output settings)
eps_switchover_time_ms
<=10
eps_voltage
Selectable Off-grid Output Voltage 110 V / 127 V / 220 V
expandable_to_kwh
—
external_transfer_switch_required
—
max_charge_current_a
—
max_charge_power_w
Maximum AC Charging Power 1.7 kW / 2.0 kW / 3.5 kW (at the 110 V / 127 V / 220 V output settings)
max_discharge_current_a
—
max_discharge_power_w
—
modules_per_stack
n/a - single all-in-one unit
nominal_capacity_ah
100
nominal_energy_kwh
5.12
nominal_voltage_v
51.2
parallel_capability
—
parallel_units_max
—
peak_discharge
Maximum Off-grid Apparent Power 2.0 kVA / 2.3 kVA / 4.0 kVA (for 1 min)
round_trip_efficiency_pct
—
usable_energy_kwh
—
voltage_range_v
44.8-57.6
Physical / mechanical
ac_terminal
Plug-in or fixed wiring
cooling
Natural Cooling
dc_connector
—
depth_mm
185
dimensions_mm
560 x 650 x 185 (W x H x D, as printed)
display
LCD / APP / Web
enclosure_material
—
height_mm
650
mounting
—
noise_db
<35
weight_kg
67.5
width_mm
560
Installation
cable_requirements
—
commissioning
—
installation_angle
—
mounting_clearances
—
torque
—
Environment
ingress_protection
IP65
max_altitude_m
—
operating_temperature_c
-20 to 55
pollution_degree
—
protective_class
—
relative_humidity_pct
—
storage_temperature_c
—
Interfaces & connectors
app
APP (name not printed)
communication
['Wi-Fi', 'Bluetooth', 'RS485']
dry_contact
—
meter_interface
—
monitoring_portal
Web
protocols
[]
Protection
anti_islanding
—
arc_fault
—
dc_switch
—
insulation_monitoring
—
overvoltage_category
—
rcmu
—
reverse_polarity
—
surge_protection_ac
—
surge_protection_dc
—
Warranty & service
conditions
NOT PRINTED on the product page. Cycle Life >=8000 cycles is printed.
extension_options
—
standard_years
—
Документи
datasheet
{# Located but never retrieved: listed, but deliberately not linked, and it
backs no stored value. #}
Dyness AquaVolt-LV Datasheet EN (DynessAquaVoltLVDatasheetEN20260717.pdf) — знайдено, не отриманоrev UNKNOWN
Записано дослівно з джерела; поля схеми для них поки немає.
AC Connection
Plug-in or fixed wiring
Cycle Life
>=8000 cycles
Maximum AC Charging Power
1.7 kW / 2.0 kW / 3.5 kW
Nominal Capacity
100 Ah
PV / solar input rows
NOT PRINTED
Sibling column on the same page
D3.6LAC-5 (AC-coupled): Nominal Battery Energy 5.12 kWh, Cycle Life >=8000, DOD 95%, IP65, Transfer Time <=10 ms, Wi-Fi / Bluetooth / LAN / RS485, 560x650x185 mm, 65 kg
