Victron Energy SmartSolar MPPT 100/15

Official manufacturer GLOBAL перевірено 20 вересня 2026 р.

Невирішений конфлікт щодо безпеки
Два джерела подають різні значення для цього продукту, і ніхто цього не вирішив. Характеристики нижче показано так, як їх записано, але цей продукт не можна вважати перевіреним для інженерних цілей, доки конфлікт не закрито.

Victron Energy SmartSolar MPPT 100/15 — PRODUCT PHOTO

Identity

category	external_mppt_controllers
ean	—
generation	—
manufacturer	Victron Energy B.V. суперечливе
market_version	—
model	SmartSolar MPPT 100/15
mpn	SCC110015060R
product_family	SmartSolar MPPT 75/10, 75/15, 100/15 & 100/20
product_status	active
region	global
release_year	—
sku	SCC110015060R
sku_source	'SCC110015060R SmartSolar MPPT 100/15 Retail'

Electrical

automatic_load_disconnect	Yes
battery_voltage_auto_select	True
battery_voltage_locator	'Battery voltage (auto select)'
battery_voltage_options_v	[12, 24]
charge_algorithm	Multi-stage adaptive or user defined
charge_voltage_absorption_v	14.4 / 28.8 V (adjustable)
charge_voltage_equalization_v	16.2V / 32.4V / 64.8V (adjustable) - manual; equalization is by default disabled (manual footnote 3)
charge_voltage_float_v	13.8 / 27.6 V (adjustable)
load_output_continuous_current_a	15A
load_output_locator	Manual §9 'Continuous load current'
low_voltage_load_disconnect_v	11.1V / 22.2V / 44.4V or 11.8V / 23.6V / 47.2V or BatteryLife
low_voltage_load_reconnect_v	13.1V / 26.2V / 52.4V or 14V / 28V / 56V or BatteryLife
max_charge_current_a	15
max_charge_current_locator	Datasheet 'Rated charge current'; manual 'Maximum battery current'
max_pv_open_circuit_voltage_locator	'Maximum PV open circuit voltage' = 100 V (no separate start-up/operating maximum is published for this family)
max_pv_open_circuit_voltage_v	100
max_pv_power_locator	'Nominal PV power, 12 V' / 'Nominal PV power, 24 V'
max_pv_power_note	Manual footnote 1a: 'The solar charger will limit input power if more PV power is connected.'
max_pv_power_w_by_battery_voltage	{'12': 220, '24': 440}
max_pv_short_circuit_current_a	15
max_pv_short_circuit_current_datasheet_a	15
max_pv_short_circuit_current_manual_a	15
mppt_operating_voltage_max_v	—
mppt_operating_voltage_min_note	Manual footnote 1b: 'The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V.'
num_trackers	—
num_trackers_note	Victron does not publish a 'number of MPP trackers' row for this model in any document fetched this session; the unit has a single PV input pair. Recorded as UNKNOWN rather than assumed. (For the 150/60 and larger families the manual does state MC4 connector pairs are internally parallel-connected to a single MPPT tracker.)
peak_efficiency_pct	98
self_consumption_datasheet	26 / 20 / 19 mA (load on); 10 / 8 / 7 mA (load off)
self_consumption_manual	12V: 20mA / 24V: 10mA
temperature_compensation	-16 mV/degC (12V) / -32 mV/degC (24V)

Physical / mechanical

depth_mm	50
dimensions_locator	'Dimensions (h x w x d)'
enclosure_material	—
height_mm	100
housing_color	Blue (RAL 5012)
mounting_type	['wall']
power_terminals	6 mm2 / AWG10
shipping_weight_kg	—
torque_specs	—
weight_kg	0.6
width_mm	113
wire_cross_section_mm2	6 mm2 / AWG10

Installation

altitude_derating_note	5000m (full rated output up to 2000m)
indoor_outdoor	Indoor type 1, unconditioned (manual 'Environmental condition')
max_installation_altitude_m	5000
mounting_orientation	—

Environment

cooling_method	—
ip_rating	IP43 (electronic), IP22 (connection area)
max_altitude_m	5000
nema_rating	—
operating_temperature_c	-30 to +60 (full rated output up to 40)
pollution_degree	PD3
relative_humidity	CONFLICT - 95% (datasheet) vs 100% (manual), both non-condensing
storage_temperature_c	—

Interfaces & connectors

battery_terminal_type	screw terminal, 6 mm2 / AWG10
bluetooth	Yes - built in (SmartSolar); 'VE.Direct port, Bluetooth via VictronConnect app'
ethernet	—
load_output	Yes - 15A continuous load current with automatic load disconnect / BatteryLife
pv_connector_type	screw terminal, 6 mm2 / AWG10
relay_outputs	—
remote_on_off	—
rs485	—
ve_can	False
ve_direct	Yes - 1 x VE.Direct port
wifi	—

Protection

over_temperature	Yes
over_voltage	—
pv_reverse_polarity	Yes
short_circuit	Output short circuit
under_voltage	—

Certifications

standards

['EN/IEC 62109-1', 'UL 1741', 'CSA C22.2 NO.107.1-16']

Warranty & service

summary

—

Документи

datasheet SmartSolar Charge Controller MPPT 75/10, 75/15, 100/15, 100/20-48V — datasheet

dimension-drawing Dimension drawing BlueSolar & SmartSolar MPPT 100/15

product-page SmartSolar MPPT 75/10, 75/15, 100/15 & 100/20 — official product page

user-manual MPPT solar charger manual SmartSolar MPPT 75/10 up to 100/20 — 9. Technical specifications

Зафіксовані конфлікти

battery_voltage_classes Review required

[12, 24, 48] —

[12, 24] —

identity.manufacturer Review required

Victron Energy B.V. — stored value

Victron Energy — incoming package

Detected during import system-topology-2026-09-batch02

physical.weight_kg / physical.dimensions Review required

0.65 kg, 100 x 131 x 60 mm — document[0]

0.6 kg, 100 x 113 x 50 mm — document[1]

electrical.self_consumption Review required

26 / 20 / 19 mA (load on); 10 / 8 / 7 mA (load off) — document[0]

12V: 20mA / 24V: 10mA — document[1]

environment.relative_humidity Review required

95 %, non-condensing — document[0]

100%, non-condensing — document[1]

Додаткові задокументовані параметри

Записано дослівно з джерела; поля схеми для них поки немає.

1b)	The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V.
2)	A higher short circuit current may damage the solar charger in case of reverse polarity connection.
3)	Equalization is by default disabled.
Automatic load disconnect	Yes
Environmental condition	Indoor type 1, unconditioned
Low voltage load disconnect	11.1V / 22.2V / 44.4V or 11.8V / 23.6V / 47.2V or BatteryLife
Low voltage load reconnect	13.1V / 26.2V / 52.4V or 14V / 28V / 56V or BatteryLife
Pollution degree	PD3
