FoxESS M1-1200-E
Official manufacturer GLOBAL перевірено 20 вересня 2026 р.
Identity
| category | microinverters |
| ean | — |
| firmware | {'documented_version': 'UNKNOWN', 'constraints': 'UNKNOWN'} |
| generation | — |
| manufacturer | FoxESS |
| market_version | — |
| model | M1-1200-E |
| mpn | — |
| product_family | M |
| product_status | active |
| region | GLOBAL |
| release_year | — |
| series | M Series |
| sku | — |
Electrical
| ac_connection | — |
| ac_voltage_range | 180 ~ 264 |
| european_efficiency_pct | 95.5 |
| frequency_range_hz | 45 ~ 55 or 55 ~ 65 |
| inrush_current | — |
| max_ac_active_power_w | — |
| max_ac_current_a | 5.46 |
| max_apparent_power_va | 1200 |
| max_backfeed_current_a | — |
| max_dc_input_power_w | — |
| max_dc_voltage_v | 60 |
| max_efficiency_pct | 96.0 |
| max_input_current_per_mppt_a | 20 |
| max_output_fault_current_a | — |
| max_short_circuit_current_per_mppt_a | 24 |
| mppt_efficiency_pct | 99.9 |
| mppt_voltage_range_v | 35 ~ 50 |
| night_self_consumption_w | — |
| nominal_ac_voltage | 230 |
| nominal_dc_voltage_v | — |
| nominal_frequency_hz | 50 or 60 |
| number_of_mppt | 2 |
| phase_count | 1 |
| power_factor_range | >0.99 ( Adjustable from 0.95 leading to 0.95 lagging ) |
| rated_ac_power_w | 1200 |
| rated_mppt_voltage_range_v | — |
| startup_voltage_v | 24 |
| strings_per_mppt | 1 |
| thd_pct | <3 |
Physical / mechanical
| ac_terminal | — |
| cooling | Natural convection-No fans |
| dc_connector | — |
| depth_mm | 34.5 |
| dimensions_mm | 270*182*34.5 |
| display | — |
| enclosure_material | — |
| height_mm | 182.0 |
| mounting | — |
| noise_db | — |
| weight_kg | 3.4 |
| width_mm | 270.0 |
Installation
| cable_requirements | Max. units per branch: 5 (10 AWG) / 4 (12 AWG) |
| commissioning | — |
| installation_angle | — |
| mounting_clearances | — |
| torque | — |
Environment
| ingress_protection | IP67 |
| max_altitude_m | — |
| operating_temperature_c | -25 ~ +65 |
| pollution_degree | — |
| protective_class | — |
| relative_humidity_pct | — |
| storage_temperature_c | — |
Interfaces & connectors
| app | — |
| communication | ['WIFI'] |
| dry_contact | — |
| meter_interface | — |
| monitoring_portal | Fox ESS Cloud |
| protocols | [] |
Protection
| anti_islanding | — |
| arc_fault | — |
| dc_switch | — |
| insulation_monitoring | — |
| overvoltage_category | — |
| rcmu | — |
| reverse_polarity | — |
| surge_protection_ac | — |
| surge_protection_dc | — |
Certifications
| standards | ['IEC62109-1/2', 'IEC 61000-6-1/2/3/4', 'IEC61000-3-2/3-3', 'ABNT NBR 16150', 'EN 50549-1: 2019', 'VDE-AR-N 4105: 2018', 'VFR2019'] |
Warranty & service
| conditions | — |
| extension_options | — |
| standard_years | — |
Документи
Додаткові задокументовані параметри
Записано дослівно з джерела; поля схеми для них поки немає.
| AC Overvoltage Category / DC Overvoltage Category | III / II |
| Applicable Module Power [W] (merged cell, all models) | 355Wp-670Wp+ |
| Dimensions / Weight (merged, all models) | 270*182*34.5 mm / 3.4 kg |
| Efficiency rows | Max. 96.00%, EU weighted 95.50%, CEC weighted 95.50%, Nominal MPPT 99.90% |
| FoxESS M1 datasheet, row 'Peak Output Apparent Power [VA]' | 1000 | 1000 | 1000 | 1000 |
| Max Units Per Branch (10 AWG / 12 AWG) | 5 / 4 |
| Max. Units Per 12 AWG Branch, column M1-1200-E | 4 |
| Night Consumption | <50 |
| PV Terminal Interlock Force [N] | 50 |
| Peak Power Tracking Voltage [V], datasheet V2.1 and user manual | 31 ~ 45 |
| Recommended PV module power | 355Wp-670Wp+ |
| Safety standards (user manual) | IEC62109-1/2; EN 50549-1: 2019 |
| manufacturer_legal_entity_as_printed | Fox ESS |
