Huawei LUNA2000-10-S0
Official manufacturer Global verified Sept. 3, 2026
Identity
| category | batteries |
| ean | UNKNOWN |
| generation | S0 (first residential generation; superseded by S1) |
| hardware_revision | UNKNOWN |
| legacy_name | None observed. |
| manufacturer | Huawei |
| market_version | UNKNOWN |
| model | LUNA2000-10-S0 |
| mpn | LUNA2000-10-S0 |
| order_code | UNKNOWN |
| product_family | LUNA2000 Smart String Energy Storage System |
| product_status | UNKNOWN |
| product_status_evidence | The S0 product page and datasheet remain live on solar.huawei.com (accessed 2026-09-03), but the S0 family does NOT appear on Huawei's current Energy Storage System products list, which shows only the S1 family for residential. No end-of-life or discontinuation statement was found in any fetched Huawei document, so status is recorded as UNKNOWN rather than guessed. |
| region | Global |
| release_year | UNKNOWN |
| sku | UNKNOWN |
| subcategory | high_voltage_stackable_dc_coupled_battery_system |
| variant_note | System-level SKU. Composed of one LUNA2000-5KW-C0 power module plus 2 x LUNA2000-5-E0 battery module(s) of 5 kWh each. |
Electrical
| architecture | HV (high-voltage DC-coupled, series-stacked) |
| cell_chemistry | Lithium-iron phosphate (LiFePO4) |
| cycle_life | UNKNOWN |
| depth_of_discharge_pct | 100 |
| expansion_rules | 1 to 3 x LUNA2000-5-E0 battery modules per system (5 / 10 / 15 kWh). Parallel operation is supported via RS485/CAN but the maximum number of parallel systems is not published. |
| firmware_requirements | UNKNOWN |
| max_charge_current_a | UNKNOWN |
| max_charge_power_kw | UNKNOWN — Huawei's S0 table states only 'Max. output power' (a DISCHARGE figure). No charging-power row is published; the output figure must not be reused as a charge limit. |
| max_discharge_current_a | UNKNOWN |
| max_discharge_power_kw | 5 |
| max_towers_or_parallel_systems | UNKNOWN — the S0 specification table has no scalability row. Parallel operation is implied by 'RS485/CAN (only for parallel operation)' but no maximum count is published in any fetched document. The S1 limit of 4 must NOT be applied to S0. |
| mixed_module_restrictions | Only one battery module type exists in this generation (LUNA2000-5-E0, 5 kWh), so no mixing question arises within S0. Mixing E0 modules with S1-generation E1 modules is NOT documented and must not be assumed. |
| module_energy_kwh | 5 (LUNA2000-5-E0) — per MODULE, not this system |
| modules_installed_this_sku | 2 |
| modules_max | 3 |
| modules_min | 1 |
| nominal_energy_kwh | UNKNOWN |
| nominal_voltage_v | 450 (with single-phase inverter) / 600 (with three-phase inverter) |
| operating_voltage_max_v | 560 (single-phase) / 980 (three-phase) |
| operating_voltage_min_v | 350 (single-phase) / 600 (three-phase) |
| peak_power_duration | 10 s |
| peak_power_kw | 7 |
| rated_power_kw | UNKNOWN |
| round_trip_efficiency_pct | UNKNOWN |
| usable_energy_kwh | 10 |
Physical / mechanical
| cooling | Natural convection |
| dimensions | 670 x 150 x 960 mm |
| dimensions_note | W x D x H, complete system including power module and 2 battery module(s). |
| ip_rating | IP 66 |
| mounting_type | Floor stand (standard), Wall mount (optional) |
| noise_emission | < 29 dB |
| weight_kg | 113.8 |
| weight_note | Huawei's label is 'Weight (with floor stand)'. |
Installation
| connectors | UNKNOWN |
| indoor_outdoor | Outdoor / Indoor |
| installation_restrictions | Footnote *4: 'Outdoor installation is recommended. For indoor installation, refer to the user manual'. Floor stand standard, wall mount optional. |
Environment
| humidity | 5% - 95% RH |
| indoor_outdoor | Outdoor / Indoor |
| max_altitude_m | 4000 (Derated above 2000 m) |
| operating_temperature | -20 C to +55 C |
| operating_temperature_charge | UNKNOWN — Huawei publishes a single combined operating range for the S0 and does NOT split charge and discharge windows in any fetched document. |
| operating_temperature_discharge | UNKNOWN — Huawei publishes a single combined operating range for the S0 and does NOT split charge and discharge windows in any fetched document. |
| storage_temperature | UNKNOWN |
Interfaces & connectors
| can | Yes — 'RS485/CAN (only for parallel operation)' |
| communication_protocol | UNKNOWN |
| display | SOC status indicator, LED indicator |
| fe_ethernet | Not listed. Unlike the S1 generation, the S0 communication row does NOT include FE/Ethernet. |
| ports | UNKNOWN |
| rs485 | Yes — 'RS485/CAN (only for parallel operation)' |
Protection
| dc_switch | UNKNOWN |
| fire_safety | Huawei marketing: built-in intelligent extinguish bag, response in 15 s. Not on the specification table. |
| ip_rating | IP 66 |
Certifications
| list | ['CE', 'RCM', 'CEC', 'VDE2510-50', 'IEC62619', 'IEC 60730', 'UN38.3'] |
| source_label | Certificates |
Warranty & service
| duration_years | UNKNOWN |
| note | No warranty row on the official S0 specification table or datasheet; no Huawei warranty letter fetched. |
Documents
product_page
LUNA2000-5-10-15-S0 Smart String Energy Storage System (product overview page)
rev UNKNOWN
user_manual
{# Located but never retrieved: listed, but deliberately not linked, and it
backs no stored value. #}
LUNA2000-5/10/15-S0 User Manual — located, not retrieved
rev UNKNOWN
Additional documented parameters
Recorded verbatim from the source; no schema field exists for these yet.
| manufacturer_legal_entity_as_printed | Huawei Technologies Co., Ltd. |
| observation:electrical.max_discharge_power_kw (LUNA2000-10-S0 vs LUNA2000-15-S0) | {"values": [{"value": "5 kW for both the 10 kWh (2-module) and 15 kWh (3-module) systems", "source": "Huawei official S0 specification page, 'Max. output power'", "source_url": "https://solar.huawei.com/en/products/luna2000-5-10-15-s0/specs/", "confidence": "officially-verified"}], "note": ""} |
