Named as a battery module of a currently documented LUNA2000 family on Huawei's official specification page (accessed 2026-09-03).
region
Global
release_year
UNKNOWN
sku
UNKNOWN
subcategory
battery_expansion_module
variant_note
Battery expansion module sold as a separate orderable item. NOT a complete system: it requires the LUNA2000-5KW-C0 power module. The energy figure below is the MODULE energy, not a system energy.
Electrical
architecture
HV (high-voltage DC-coupled, series-stacked)
cell_chemistry
Lithium-iron phosphate (LiFePO4)
cycle_life
UNKNOWN
depth_of_discharge_pct
100
expansion_rules
UNKNOWN
firmware_requirements
UNKNOWN
max_charge_current_a
UNKNOWN
max_charge_power_kw
UNKNOWN
max_discharge_current_a
UNKNOWN
max_discharge_power_kw
UNKNOWN
max_towers_or_parallel_systems
UNKNOWN
mixed_module_restrictions
UNKNOWN
module_energy_kwh
5
modules_max
3
modules_min
1
modules_note
Number of these modules installable in one tower beneath a single power module.
nominal_energy_kwh
UNKNOWN
nominal_voltage_v
UNKNOWN — Huawei does not publish a module-level nominal voltage. The 350-560 V / 600-980 V figures are SYSTEM DC-bus ranges seen by the inverter and must not be recorded as this module's nominal voltage.
operating_voltage_max_v
UNKNOWN
operating_voltage_min_v
UNKNOWN
peak_power_duration
UNKNOWN
peak_power_kw
UNKNOWN
rated_power_kw
UNKNOWN
round_trip_efficiency_pct
UNKNOWN
usable_energy_kwh
5
Physical / mechanical
cooling
Natural convection (system-level figure)
dimensions
670 x 150 x 360 mm
dimensions_note
W x D x H, battery module only.
ip_rating
UNKNOWN
ip_rating_note
IP66 is published for the assembled system, not separately for this module.
mounting_type
Stacked column beneath the power module (floor stand standard, wall mount optional)
weight_kg
50
Installation
connectors
UNKNOWN
indoor_outdoor
Outdoor / Indoor (system-level figure)
installation_restrictions
Requires the LUNA2000-5KW-C0 power module; cannot operate standalone.
Environment
humidity
5% - 95% (system-level figure)
indoor_outdoor
Outdoor / Indoor (system-level figure)
max_altitude_m
4000 (system-level figure)
operating_temperature
-20 C to +55 C (published for the assembled system)
operating_temperature_charge
UNKNOWN
operating_temperature_discharge
UNKNOWN
storage_temperature
UNKNOWN
Interfaces & connectors
can
UNKNOWN
communication_protocol
UNKNOWN
ports
Battery cascading connection to the power module / adjacent modules (exact port set not published at module level)
user_manual
{# Located but never retrieved: listed, but deliberately not linked, and it
backs no stored value. #}
LUNA2000-5/10/15-S0 User Manual — located, not retrievedrev UNKNOWN
Additional documented parameters
Recorded verbatim from the source; no schema field exists for these yet.
