Pylontech Fidus Battery Plus
Unknown GLOBAL
Identity
| aliases | ['Fidus Battery+', 'Fidus Plus'] |
| brand | Pylontech |
| category | batteries |
| manufacturer | Pylontech |
| manufacturer_key | pylontech |
| model | Fidus Battery Plus |
| model_key | fidus-battery-plus |
| model_numbers | ['FB-L-16', 'FB-L-16-Pro', 'FB-L-16-PK'] |
| product_family | Fidus Series (Low Voltage) |
| product_status | active |
| region | GLOBAL |
| release_year | 2025 |
Electrical
| charge_current_a | 180/200 (max continuous) |
| chemistry | LiFePO4 (LFP) |
| cycle_life | 8,000@100% DoD @ 25C |
| depth_of_discharge_pct | 100 |
| design_life_years | 15 |
| discharge_current_a | 180/200 (max continuous); 300A peak @15s |
| nominal_energy_kwh | 16.076 |
| usable_energy_kwh | 16.076 |
| voltage_v | 51.2 |
Physical / mechanical
| dimensions_wdh_mm | 435*240*900 |
| weight_kg | {'FB-L-16': 120, 'FB-L-16-Pro': 122, 'FB-L-16-PK': 130} |
Installation
| system_rules | {'max_modules_single_group': {'FB-L-16': 16, 'FB-L-16-Pro': 16, 'FB-L-16-PK': 20}, 'max_strings': 6, 'lv_hub_required': True, 'notes': 'LV-HUB-V2 required for parallel; built-in display panel; fire suppression (aerosol optional); FB-L-16-Pro includes low-temperature heating for cold regions; 10kW continuous / 15kW short-burst power per battery'} |
Environment
| altitude_m | <=4000 |
| anti_corrosion | C5-M |
| humidity | 5%~95% No Condensation |
| storage_temperature_c | -20~60 |
| working_temperature_charge_c | {'FB-L-16': '0~55', 'FB-L-16-Pro': '-20~55', 'FB-L-16-PK': '0~60'} |
| working_temperature_discharge_c | 20~60 |
Interfaces & connectors
| communication | ['RS485', 'CAN'] |
Protection
| ip_rating | IP65 (FB-L-16, FB-L-16-Pro) / IP20 (FB-L-16-PK) |
Certifications
| standards | ['IEC62619', 'IEC63056', 'UN38.3', 'EMC', 'CE'] |
Documents
product-page
Fidus Battery Plus source
Additional documented parameters
Recorded verbatim from the source; no schema field exists for these yet.
| source.category | residential_lv |
| source.status | current |
