Named as the power module of the currently listed LUNA2000-S0 family on Huawei's official specification page (accessed 2026-09-03).
region
Global
release_year
UNKNOWN
sku
UNKNOWN
subcategory
battery_power_control_module
variant_note
Power / control module of a LUNA2000 tower. STORES NO ENERGY. Sold as a separate orderable item. Exactly one is required per system; battery modules stack beneath it.
Electrical
architecture
HV (high-voltage DC-coupled)
cell_chemistry
N/A (contains no cells)
cycle_life
N/A
depth_of_discharge_pct
N/A
energy_note
This product stores NO energy. Any kWh figure associated with it in the wild is a SYSTEM figure and must never be attached to this record.
expansion_rules
Verbatim: 'Power module model: LUNA2000-5KW-C0'; 'Number of power modules: 1'; power module dimensions '670 x 150 x 240 mm'; power module weight '12 kg'. This module caps the S0 system at 5 kW output — the 3-module 15 kWh system has the same 5 kW output as the 2-module 10 kWh system. Huawei publishes no standalone electrical rating table for this module; voltage, current, efficiency and temperature limits are system-level only and are recorded UNKNOWN here rather than copied down.
firmware_requirements
UNKNOWN
max_charge_current_a
UNKNOWN
max_charge_power_kw
UNKNOWN
max_discharge_current_a
UNKNOWN
max_discharge_power_kw
UNKNOWN
max_towers_or_parallel_systems
UNKNOWN
mixed_module_restrictions
UNKNOWN
module_energy_kwh
0
modules_max
3
modules_min
1
modules_note
Number of BATTERY modules this power module supports beneath it.
nominal_energy_kwh
0
nominal_voltage_v
UNKNOWN
operating_voltage_max_v
UNKNOWN
operating_voltage_min_v
UNKNOWN
peak_power_duration
UNKNOWN
peak_power_kw
UNKNOWN
rated_power_kw
UNKNOWN
round_trip_efficiency_pct
UNKNOWN
usable_energy_kwh
0
Physical / mechanical
cooling
Natural convection (system-level figure)
dimensions
670 x 150 x 240 mm
dimensions_note
W x D x H, power module only.
ip_rating
UNKNOWN
ip_rating_note
The IP66 rating is published for the assembled system, not separately for this module.
mounting_type
Stacks on top of the battery module column (floor stand standard, wall mount optional)
weight_kg
12
Installation
connectors
UNKNOWN
indoor_outdoor
Outdoor / Indoor (system-level figure)
installation_restrictions
One power module per system.
Environment
humidity
UNKNOWN
indoor_outdoor
Outdoor / Indoor (system-level figure)
max_altitude_m
UNKNOWN
operating_temperature
UNKNOWN at module level — Huawei publishes -20 C to +55 C for the assembled system only.
operating_temperature_charge
UNKNOWN
operating_temperature_discharge
UNKNOWN
storage_temperature
UNKNOWN
Interfaces & connectors
can
UNKNOWN
communication_protocol
UNKNOWN
ports
UNKNOWN
rs485
UNKNOWN
Protection
ip_rating
UNKNOWN
Certifications
list
[]
note
Certificates are published for the system, not this module separately.
user_manual
{# Located but never retrieved: listed, but deliberately not linked, and it
backs no stored value. #}
LUNA2000-5/10/15-S0 User Manual — located, not retrievedrev UNKNOWN
Additional documented parameters
Recorded verbatim from the source; no schema field exists for these yet.
