ABB (E-mobility; NA distribution via InCharge Energy) Terra AC Wallbox
Official manufacturer global (separate IEC and UL/Japan portfolios) verified Sept. 2, 2026
ABB product page for Terra AC type code TAC-W11-G5-R-0, official ABB product-image CDN
ABB Terra AC Wallbox landing page banner ('TERRA-AC_websitebanner')
Identity
| cable_or_socket | Type 2 cable, Type 2 socket, or Type 2 socket with shutter (IEC 62196-1/2); Type 1 (SAE J1772) cable for UL/Japan, 7.6 m (25 ft) |
| category | ev_chargers |
| ean | UNKNOWN |
| manufacturer | ABB (E-mobility; NA distribution via InCharge Energy) |
| market_version | IEC (CE/MID) and UL/Japan variants documented in one installation manual |
| model | Terra AC Wallbox |
| mpn | see sku |
| product_family | ABB Terra AC wallbox |
| product_status | active |
| region | global (separate IEC and UL/Japan portfolios) |
| sku | IEC/NA type codes seen this session: 6AGC081287 (32 A, RFID, daisy-chain Ethernet), 6AGC081288 (32 A + 4G), 6AGC081290 (32 A + 4G + screen), 6AGC105905 (40 A), 6AGC082553 (40 A + 4G + screen), 6AGC105904 (80 A), 6AGC081291 (80 A + 4G + screen), 6AGC082156 / TAC-W11-G5-R-0 |
Electrical
| adjustable_current_range_a | 5-80A in 1A increments (installer-configured max; further adjustable via OCPP Smart Charging/CMS) |
| api_cloud | True |
| api_local | True |
| dynamic_load_balancing | UNKNOWN explicit statement, but generically supported via OCPP Smart Charging / ABB CMS |
| home_assistant_integration | none-known |
| max_current_a | 80 |
| max_power_kw | 19.2 |
| meter_integration | ['ABB EQmatic Energy Analyzer (documented Modbus integration guide)'] |
| modbus_support | True |
| mqtt_support | UNKNOWN (not documented) |
| ocpp_support | OCPP 1.6J |
| phase_type | configurable single/three-phase, 32/40/48/80A current variants |
| solar_surplus_charging | UNKNOWN/likely false (commercial/fleet-oriented product, no native solar-surplus feature documented) |
| supported_inverter_ems_integrations | UNKNOWN (Modbus/OCPP interfaces could enable generic third-party EMS integration, no named partnerships) |
Physical / mechanical
| cable_length_m | 7.6 |
| depth_mm | 125 |
| enclosure_material | rugged metal enclosure (InCharge NA spec sheet) |
| height_mm | 400 |
| housing_color | UNKNOWN |
| mounting_bolt_size |
upper screws M6 x 60 with 8 x 60 mm plugs; lower screws M6 x 120 with 10 x 60 mm plugs (all supplied)
Installation manual Terra AC (BCM.V3Y01.0-EN V006) — installation manual, mechanical installation: 'Upper screws M6 x 60 ... Lower screws M6 x 120'
|
| mounting_hole_spacing_mm | UNKNOWN (upper mounting screws must protrude 6 mm from the wall) |
| mounting_type | ['wall', 'pedestal'] |
| shipping_weight_kg | UNKNOWN |
| terminal_locations | supply terminal block (IEC 2.5-10 mm2, strip 10 mm; UL 12-6 AWG, strip 10 mm); RS485 terminal block (0.5-2.5 mm2 / 12-30 AWG, strip 5 mm); dry-contact input and output blocks |
| torque_specs | dry-contact terminal blocks 0.5 N.m; supply terminal torque per installation manual Section 11.15 |
| weight_kg | 3.0 (socket model) to 7.0 (cable models) per the installation manual; NA 40 A unit 10.8 kg and 80 A unit 11.8 kg per the UL datasheet (packaged/with cable) |
| width_mm | 230 |
Installation
| clearance_top_mm | 200 |
| indoor_outdoor | Indoor and outdoor |
| max_installation_altitude_m | 4000 |
| minimum_wall_thickness_mm |
89
Installation manual Terra AC (BCM.V3Y01.0-EN V006) — installation manual, wall requirements: 'Minimum thickness 89 mm (3.5 inches)'
|
| mounting_height_mm | horizontal/mounting range 450-1200 mm indoor; 600-1200 mm outdoor |
| mounting_orientation | vertical wall mount or pedestal |
| required_rcd_type |
IEC: 'Minimum Type A, with a rated residual operation current of maximum 30 mA' upstream; the charger adds internal DC fault-current monitoring > 6 mA. UL/Japan: internal 20 mA AC CCID, no external GFCI specified.
Installation manual Terra AC (BCM.V3Y01.0-EN V006) — installation manual: 'Minimum Type A, with a rated residual operation current of maximum 30 mA'
|
| required_upstream_breaker |
IEC: MCB or RCBO, Type C characteristic - 40 A for a 32 A rated EVSE, 20 A for a 16 A rated EVSE. UL/Japan: 40 A (32 A EVSE) or 20 A (16 A EVSE), Type C, acting as main disconnect. NA datasheet recommends 40 A / 50 A / 100 A for the 32 A / 40 A / 80 A units.
Installation manual Terra AC (BCM.V3Y01.0-EN V006) — installation manual, upstream protection: '40 A for a 32 A rated EVSE; 20 A for a 16 A rated EVSE'
|
| supply_cable_requirements | IEC: 2.5-10 mm2 (6 mm2 recommended for 32 A, 2.5 mm2 for 16 A). UL/Japan: 6-12 AWG (8 AWG for 32 A, 12 AWG for 16 A) |
| surface_requirements | brick, concrete, or finished stable surface; minimum wall thickness 89 mm (3.5 in) |
Environment
| cooling_method | UNKNOWN |
| ik_rating | IK10 (IEC 62262) |
| ip_rating | IP65 (NA datasheet); IEC units per product label |
| max_altitude_m |
4000
PRODUCT DATA SHEET Terra AC Wallbox UL 32/40/80 A Level 2 EV charger — UL datasheet: 'Altitude 4000 m (13,123 ft)'
|
| nema_rating | NEMA 4 (NA variants) |
| operating_temperature_c | -35 to +50 (MID models -30 to +55); NA datasheet: -30 to +55 with derating |
| relative_humidity | <95%, non-condensing |
| storage_temperature_c | -40 to +80 (installation manual); -40 to +85 (NA datasheet) |
Interfaces & connectors
| bluetooth | BLE 5.0 |
| cellular | 4G / LTE / WCDMA via nano-M2M SIM socket |
| cloud_api | ChargerSync portal / app; TerraConfig commissioning app (iOS 8+, Android 4.4+) |
| connector_type | IEC: Type 2 cable / socket / socket with shutter (IEC 62196-1/2). UL/Japan: Type 1 SAE J1772 cable, 7.6 m (25 ft), 'J2CE - Canted Coil Spring' |
| dry_contacts | 1 configurable input + 1 configurable output; output rated 125 VAC / 30 VDC at 3 A |
| ethernet | 1x 10/100 BaseT RJ45 primary + secondary RJ45 for daisy-chaining |
| load_balancing | via external energy meter on Modbus RTU RS485 or a local controller; also OCPP 1.6J smart charging from a central system |
| local_api | UNKNOWN |
| meter_inputs | external smart meter on RS485/Modbus RTU; internal revenue-grade energy meter Class B (+/-2%), MID/PTB certified on IEC models |
| modbus_rtu | yes (RS485, energy meter or local controller connection) |
| modbus_tcp | yes |
| mqtt | UNKNOWN |
| ocpp | OCPP 1.6J |
| protocol_notes | ABB documents no inverter-brand-specific solar integration for the Terra AC. Solar-surplus behaviour is achieved through an external EMS/local controller on Modbus RTU/TCP or through OCPP smart charging. A separate ABB application note covers KNX integration via a Modbus-KNX gateway (located, not fetched). |
| rfid | ISO/IEC 14443A, MIFARE Classic 1K and 4K |
| rs485 |
RS485 terminal block for smart meter / Modbus RTU; 9600 bps default, configurable via TerraConfig; wire 0.5-2.5 mm2 (IEC) or 12-30 AWG (UL), 24 AWG / 0.5 mm2 minimum recommended
Installation manual Terra AC (BCM.V3Y01.0-EN V006) — installation manual, RS485 smart-meter/Modbus RTU section
|
| wifi | IEEE 802.11 b/g/n, 2.4 GHz |
Controls & display
| buttons | current limit set by rotary switch |
| display_type | optional screen display (-D / screen-display SKUs); wake-up by touch |
| leds | 5 LEDs (power / connectivity / authorization / charging / error) |
| local_display | optional |
| mobile_app | ChargerSync app; TerraConfig app (installer) |
| touchscreen | False |
| web_interface | ChargerSync web portal |
Protection
| dc_leakage_detection |
DC fault current monitoring > 6 mA (IEC portfolio)
Installation manual Terra AC (BCM.V3Y01.0-EN V006) — installation manual: 'DC fault current monitoring > 6 mA'
|
| ground_fault_protection | IEC: earth fault 30 mA AC + 6 mA DC. UL/Japan: internal 20 mA AC CCID |
| over_current | yes (0x0020) and severe over-current (0x0040) |
| over_temperature | yes (error code 0x0080) |
| over_voltage | yes (error code 0x0008) |
| overvoltage_category | III |
| pen_fault_detection | PE missing / phase swap detection (error code 0x0004); missing phase (0x2000) |
| protection_class | UNKNOWN |
| residual_current_monitoring | yes (error code 0x0002) |
| short_circuit | UNKNOWN |
| surge_protection | integrated surge protection |
| under_voltage | yes (error code 0x0010) |
| welded_relay_detection | power relay fault detection (error code 0x0400) |
Certifications
| emc | ['EN 61000-6-1', 'EN 61000-6-2', 'EN 61000-6-3', 'EN 61000-6-4', 'IEC 61851-21-2', 'EN 301 908-1/2/13', 'EN 300 328', 'EN 301 489-1/3/17/52', 'EN 300 330', 'FCC Part 15B', 'FCC Part 15C'] |
| grid_codes | [] |
| other | ['MID', 'PTB', 'EN 50385', 'EN 50470-1', 'EN 50470-3', 'SGS certificate SGSNA/21/SH/00292 (InCharge NA spec sheet)'] |
| regional | ['CE', 'cTUVus', 'JATE', 'TELEC', "ENERGY STAR (part of US models; NA datasheet notes 'Except the 32A charger')"] |
| safety | ['IEC/EN 61851-1', 'IEC 62955', 'UL 2594', 'UL 2231-1', 'UL 2231-2', 'UL 1998', 'CSA C22.2 No.280', 'NMX-J-667-ANCE', 'IEC 62262 (IK10)'] |
Warranty & service
| conditions | '24 months' per the ABB Terra AC Wallbox UL 32/40/80 A product data sheet. The InCharge Energy NA spec sheet v1.6 instead states 'Standard 3-year (36 month) Warranty' with customizable parts/labour/uptime-SLA options - see data_conflicts. |
| design_life_years | UNKNOWN |
| extended_options_years | UNKNOWN |
| standard_years |
2
PRODUCT DATA SHEET Terra AC Wallbox UL 32/40/80 A Level 2 EV charger — UL datasheet: '24 months'
|
Documents
communication-manual
{# Located but never retrieved: listed, but deliberately not linked, and it
backs no stored value. #}
Integration of a Terra AC Wallbox into a KNX System via Modbus-KNX Gateway — located, not retrieved
installation-manual
{# Located but never retrieved: listed, but deliberately not linked, and it
backs no stored value. #}
Pedestal for Terra AC wallbox Installation manual (9AKK107991A5012) — located, not retrieved
product-page
Terra AC Wallbox product page (ABB)
Recorded conflicts
environment.operating_temperature_c Review required
-35 C to +50 C (MID models -30 to +55) — ABB Terra AC installation manual BCM.V3Y01.0-EN V006, fetched 2026-09-02
-30 C to +55 C, derating may apply — ABB UL product data sheet + InCharge spec sheet, fetched 2026-09-02
different portfolio (IEC non-MID vs MID vs UL); both are ABB documents
current variants offered Review required
32 A / 40 A / 80 A (7.4 / 9.6 / 19.2 kW) — ABB UL product data sheet, fetched 2026-09-02
32 A / 40 A / 48 A / 80 A — InCharge Energy spec sheet v1.6, fetched 2026-09-02
the 48 A / 11.5 kW configuration appears only in the distributor sheet; it may be a distributor-configured derating of the 80 A unit or a newer SKU not in the 2023 ABB datasheet.
warranty.standard_years Review required
24 months — ABB 'PRODUCT DATA SHEET Terra AC Wallbox UL 32/40/80 A' (library.e.abb.com, 2023), fetched 2026-09-02
Standard 3-year (36 month) Warranty — InCharge Energy 'InCharge_Specsheet_ABB-Terra-AC_v1.6' (inchargeus.com), fetched 2026-09-02
InCharge Energy is the NA distributor and appears to bundle an extended distributor warranty; ABB's own datasheet states 24 months. Stored value = 24 months (better-sourced, manufacturer document).
environment.operating_temperature_c Review required
-35 C to +50 C (MID models -30 to +55) — ABB Terra AC installation manual BCM.V3Y01.0-EN V006, fetched 2026-09-02
-30 C to +55 C, derating may apply — ABB UL product data sheet + InCharge spec sheet, fetched 2026-09-02
different portfolio (IEC non-MID vs MID vs UL); both are ABB documents
current variants offered Review required
32 A / 40 A / 80 A (7.4 / 9.6 / 19.2 kW) — ABB UL product data sheet, fetched 2026-09-02
32 A / 40 A / 48 A / 80 A — InCharge Energy spec sheet v1.6, fetched 2026-09-02
the 48 A / 11.5 kW configuration appears only in the distributor sheet; it may be a distributor-configured derating of the 80 A unit or a newer SKU not in the 2023 ABB datasheet.
warranty.standard_years Review required
24 months — ABB 'PRODUCT DATA SHEET Terra AC Wallbox UL 32/40/80 A' (library.e.abb.com, 2023), fetched 2026-09-02
Standard 3-year (36 month) Warranty — InCharge Energy 'InCharge_Specsheet_ABB-Terra-AC_v1.6' (inchargeus.com), fetched 2026-09-02
InCharge Energy is the NA distributor and appears to bundle an extended distributor warranty; ABB's own datasheet states 24 months. Stored value = 24 months (better-sourced, manufacturer document).
Additional documented parameters
Recorded verbatim from the source; no schema field exists for these yet.
| Adjustable output current (NA distributor) | 5A to 80A in 1A increments |
| Dry contact output rating | 125 VAC / 30 VDC at 3 A |
| Error/fault code map | 0x0002 residual current; 0x0004 PE missing/phase swap; 0x0008 overvoltage; 0x0010 undervoltage; 0x0020 overcurrent; 0x0040 severe overcurrent; 0x0080 over temperature; 0x0400 power relay fault; 0x0800 internal communication failure; 0x1000 E-Lock failure; 0x2000 missing phase; 0x4000 Modbus communication loss |
| Installation time claim | Designed for installation in less than 30 min |
| MID current rating | 0.25-5(32)A maximum for MID-certified models |
| Modbus baud rate | 9600 bps standard (configurable via TerraConfig app) |
| Standby power | 4.6 W (CE/MID), 3.6 W (UL/Japan) |
| Upper mounting screw protrusion | Upper mounting screws protrude 6 mm from wall |
