Identity

category	external_mppt_controllers
ean	UNKNOWN
generation	UNKNOWN
manufacturer	Victron Energy B.V.
market_version	UNKNOWN
model	SmartSolar MPPT 100/20-48V
mpn	UNKNOWN
product_family	SmartSolar MPPT 75/10, 75/15, 100/15 & 100/20
product_status	active
region	global
release_year	UNKNOWN
sku	UNKNOWN
variant_note	The datasheet column is headed 'MPPT 100/20-48V'; the manual column and the product page both call it 'MPPT 100/20'. Treated as one product. Its load output is current-limited to 1 A on a 48 V battery, versus 20 A on 12 V and 24 V - do not flatten.

Electrical

automatic_load_disconnect	Yes
battery_voltage_auto_select	True
battery_voltage_locator	'Battery voltage (auto select)'
battery_voltage_options_v	[12, 24, 48]
charge_algorithm	Multi-stage adaptive or user defined
charge_voltage_absorption_v	14.4 / 28.8 / 57.6 V (adjustable)
charge_voltage_equalization_v	16.2V / 32.4V / 64.8V (adjustable) - manual; equalization is by default disabled (manual footnote 3)
charge_voltage_float_v	13.8 / 27.6 / 55.2 V (adjustable)
load_output_continuous_current_a	12V & 24V: 20A / 48V: 1A
load_output_locator	Manual §9 'Continuous load current'
low_voltage_load_disconnect_v	11.1V / 22.2V / 44.4V or 11.8V / 23.6V / 47.2V or BatteryLife
low_voltage_load_reconnect_v	13.1V / 26.2V / 52.4V or 14V / 28V / 56V or BatteryLife
max_charge_current_a	20
max_charge_current_locator	Datasheet 'Rated charge current'; manual 'Maximum battery current'
max_pv_open_circuit_voltage_locator	'Maximum PV open circuit voltage' = 100 V (no separate start-up/operating maximum is published for this family)
max_pv_open_circuit_voltage_v	100
max_pv_power_locator	'Nominal PV power, 12 V' / 'Nominal PV power, 24 V' / 'Nominal PV power, 48 V'
max_pv_power_note	Manual footnote 1a: 'The solar charger will limit input power if more PV power is connected.'
max_pv_power_w_by_battery_voltage	{'12': 290, '24': 580, '48': 1160}
max_pv_short_circuit_current_a	20
max_pv_short_circuit_current_datasheet_a	20
max_pv_short_circuit_current_manual_a	20
mppt_operating_voltage_max_v	UNKNOWN
mppt_operating_voltage_min_note	Manual footnote 1b: 'The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V.'
num_trackers	UNKNOWN
num_trackers_note	Victron does not publish a 'number of MPP trackers' row for this model in any document fetched this session; the unit has a single PV input pair. Recorded as UNKNOWN rather than assumed. (For the 150/60 and larger families the manual does state MC4 connector pairs are internally parallel-connected to a single MPPT tracker.)
peak_efficiency_pct	98
self_consumption_datasheet	26 / 20 / 19 mA (load on); 10 / 8 / 7 mA (load off)
self_consumption_manual	12V: 25mA / 24V & 48V: 15mA
temperature_compensation	-16 mV/degC (12V) / -32 mV/degC (24V) / -64 mV/degC (48V)

Physical / mechanical

depth_mm	60
dimensions_locator	'Dimensions (h x w x d)'
enclosure_material	UNKNOWN
height_mm	100
housing_color	Blue (RAL 5012)
mounting_type	['wall']
power_terminals	6 mm2 / AWG10
shipping_weight_kg	UNKNOWN
torque_specs	UNKNOWN
weight_kg	0.65
width_mm	131
wire_cross_section_mm2	6 mm2 / AWG10

Installation

altitude_derating_note	5000m (full rated output up to 2000m)
indoor_outdoor	Indoor type 1, unconditioned (manual 'Environmental condition')
max_installation_altitude_m	5000
mounting_orientation	UNKNOWN

Environment

cooling_method	UNKNOWN (no fan row published)
ip_rating	IP43 (electronic), IP22 (connection area)
max_altitude_m	5000
nema_rating	UNKNOWN
operating_temperature_c	-30 to +60 (full rated output up to 40)
pollution_degree	PD3
relative_humidity	CONFLICT - 95% (datasheet) vs 100% (manual), both non-condensing
storage_temperature_c	UNKNOWN

Interfaces & connectors

battery_terminal_type	screw terminal, 6 mm2 / AWG10
bluetooth	Yes - built in (SmartSolar); 'VE.Direct port, Bluetooth via VictronConnect app'
ethernet	UNKNOWN
load_output	Yes - 12V & 24V: 20A / 48V: 1A continuous load current with automatic load disconnect / BatteryLife
pv_connector_type	screw terminal, 6 mm2 / AWG10
relay_outputs	UNKNOWN (not published for this family)
remote_on_off	UNKNOWN
rs485	UNKNOWN
ve_can	False
ve_direct	Yes - 1 x VE.Direct port
wifi	UNKNOWN

Protection

over_temperature	Yes
over_voltage	UNKNOWN
pv_reverse_polarity	Yes
short_circuit	Output short circuit
under_voltage	UNKNOWN

Certifications

standards

['EN/IEC 62109-1', 'UL 1741', 'CSA C22.2 NO.107.1-16']

Warranty & service

summary

UNKNOWN (Victron's 5-year standard warranty is stated on other SmartSolar product pages but was not quoted on the page fetched for this family)

Documents

datasheet SmartSolar Charge Controller MPPT 75/10, 75/15, 100/15, 100/20-48V — datasheet

product-page SmartSolar MPPT 75/10, 75/15, 100/15 & 100/20 — official product page

user-manual MPPT solar charger manual SmartSolar MPPT 75/10 up to 100/20 — 9. Technical specifications

Recorded conflicts

electrical.self_consumption Review required

26 / 20 / 19 mA (load on); 10 / 8 / 7 mA (load off) — document[0]

12V: 25mA / 24V & 48V: 15mA — document[1]

environment.relative_humidity Review required

95 %, non-condensing — document[0]

100%, non-condensing — document[1]

Additional documented parameters

Recorded verbatim from the source; no schema field exists for these yet.

1b)	The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V.
2)	A higher short circuit current may damage the solar charger in case of reverse polarity connection.
3)	Equalization is by default disabled.
Automatic load disconnect	Yes
Environmental condition	Indoor type 1, unconditioned
Low voltage load disconnect	11.1V / 22.2V / 44.4V or 11.8V / 23.6V / 47.2V or BatteryLife
Low voltage load reconnect	13.1V / 26.2V / 52.4V or 14V / 28V / 56V or BatteryLife
Pollution degree	PD3

Victron Energy SmartSolar MPPT 100/20-48V
