SolaX Power EMS1000 PRO
Official manufacturer GLOBAL verified Sept. 23, 2026
Identity
| category | gateways |
| manufacturer | SolaX Power |
| model | EMS1000 PRO |
| product_status | active |
| region | GLOBAL |
Electrical
| can_detail |
CAN-FD x 2, CAN-2.0 x 1
EMS1000 PRO | Monitoring Device
|
| cellular_4g |
CAT4
EMS1000 PRO | Monitoring Device
|
| cloud_uplink |
WAN NET4, 10 M / 100 M / 1000 Mbps
EMS1000 PRO | Monitoring Device
|
| installation |
DIN-rail mounting, Wall mounting
EMS1000 PRO | Monitoring Device
|
| lan_ports |
NET1 / NET2 / NET3, 10 / 100 / 1000 Mbps
EMS1000 PRO | Monitoring Device
|
| max_connected_inverters |
120
EMS1000 PRO | Monitoring Device
|
| max_slave_devices |
10
EMS1000 PRO | Monitoring Device
|
| official_product_url |
https://www.solaxpower.com/our-products/ems1000pro.html
EMS1000 PRO | Monitoring Device
|
| rs485_port_count |
8
EMS1000 PRO | Monitoring Device
|
| sample_rate |
Per 10 seconds, 2G data package
EMS1000 PRO | Monitoring Device
|
| sim_card |
Nano - 4 FF, 12.3 x 8.8 mm; Class C, 1.8 V
EMS1000 PRO | Monitoring Device
|
| supply_voltage | 100-240 V AC |
| wan_port |
NET2, 10 / 100 / 1000 Mbps
EMS1000 PRO | Monitoring Device
|
Physical / mechanical
| height_mm |
59
EMS1000 PRO | Monitoring Device
|
| length_mm |
232
EMS1000 PRO | Monitoring Device
|
| mounting | DIN-rail |
| weight_kg |
1.4
EMS1000 PRO | Monitoring Device
|
| width_mm |
113.2
EMS1000 PRO | Monitoring Device
|
Environment
| ip_rating | IP20 |
| operating_temperature_max_c | 60.0 |
| operating_temperature_min_c | -25.0 |
Interfaces & connectors
| can | True |
| interfaces | RS485, Ethernet, Wi-Fi |
| local_web_ui |
True
EMS1000 PRO | Monitoring Device
|
| supported_devices_max | 32 |
Documents
product_page
EMS1000 PRO | Monitoring Device
Additional documented parameters
Recorded verbatim from the source; no schema field exists for these yet.
| builder_completeness | partial |
| region_notes | SolaX global English site, Monitoring Devices category; one specification, no regional split printed. |
| withheld:can_port_count | 3 |
