{'documented_version': 'from firmware version 4.00.00.R', 'constraints': 'Quick Reference Guide SBxx-1AV-41-IS-xx-18 is valid from firmware version 4.00.00.R'}
generation
-1AV-41
manufacturer
SMA
market_version
EU / international (SMA Grid Guard 10.0 country data sets)
model
SB4.0-1AV-41 (Sunny Boy 4.0)
mpn
—
product_family
Sunny Boy
product_status
active
region
EU
release_year
—
series
Sunny Boy 3.0 / 3.6 / 4.0 / 5.0 / 6.0
sku
—
Electrical
ac_connection
AC connector
ac_voltage_range
180 V to 280 V
battery_type
Not applicable - PV string inverter without battery input
eps_peak_power
—
eps_phase
—
eps_rated_power_va
—
eps_switchover_time_ms
—
eps_voltage
—
european_efficiency_pct
96.5
external_transfer_switch_required
—
frequency_range_hz
45 Hz to 55 Hz at 50 Hz; 55 Hz to 65 Hz at 60 Hz (grid frequency 50 Hz / 60 Hz)
inrush_current
< 20 % of nominal AC current for a maximum of 10 ms
max_ac_active_power_w
—
max_ac_current_a
18.2
max_apparent_power_va
4000
max_backfeed_current_a
0
max_dc_input_power_w
7500
max_dc_voltage_v
600
max_efficiency_pct
97.0
max_input_current_per_mppt_a
15
max_output_fault_current_a
29
max_short_circuit_current_per_mppt_a
20
mppt_efficiency_pct
—
mppt_voltage_range_v
140 V to 500 V
night_self_consumption_w
5
nominal_ac_voltage
220 V / 230 V / 240 V (nominal grid voltage); rated grid voltage 230 V
nominal_dc_voltage_v
365
nominal_frequency_hz
50
number_of_mppt
2
parallel_capability
—
phase_count
1
power_factor_range
1 at rated power
rated_ac_power_w
4000
rated_mppt_voltage_range_v
—
startup_voltage_v
125
strings_per_mppt
2
thd_pct
3
Physical / mechanical
ac_terminal
AC connector
cooling
Convection
dc_connector
SUNCLIX DC connector
depth_mm
176
dimensions_mm
435 x 470 x 176
display
Via smartphone, tablet or laptop (integrated web UI)
enclosure_material
—
height_mm
470
mounting
Wall mounting bracket
noise_db
25
weight_kg
17.5
width_mm
435
Installation
cable_requirements
—
commissioning
—
installation_angle
—
mounting_clearances
—
torque
—
Environment
ingress_protection
IP65
max_altitude_m
—
operating_temperature_c
-25 to +60
pollution_degree
—
protective_class
—
relative_humidity_pct
0 % to 100 % (extended humidity range, IEC 60721-3-3 class 4K4H)
user-manual
{# Located but never retrieved: listed, but deliberately not linked, and it
backs no stored value. #}
Operating manual SUNNY BOY 3.0 / 3.6 / 4.0 / 5.0 / 6.0 (SBxx-1AV-41-BE-en-21) — located, not retrievedrev SBxx-1AV-41-BE-en-21
